SEWARD SHIPYARD FACILITY


The JAG Alaska Inc., Seward Shipyard facility is an eleven acre, full service shipyard with two drydocks, the SyncroLift vertical lift drydock and the TravelLift.  The shipyard’s cranes provide lifting capacity up to 80 tons.  The yard’s covered work area encompasses 35, 000 sq. ft. of covered work area among other open work areas and provisions. A system of marine rails and transfer carriages employed for vessel transport, enabling vessels to be moved from drydock to one of the several work areas, accommodating  up to 4 large vessels at any given time. The facility also includes on-site Machine, Fabrication and Paint shops

The facility’s strategic location enables JAG to provide services across the rich gamut of Alaska’s marine industries including fishing, marine transportation and both oil and gas industries. The facility is also amply equipped to service US Coast Guard vessels in the region.

The Seward Shipyard is the second largest shipyard north of Seattle.  Situated in Seward, Alaska on Resurrection Bay, the our facility is the closest shipyard of similar capacity to more than two thirds of the Alaskan Coastline and the majority of the Alaskan fleet harboring  from Yukatat to Kodiak to Prudhoe Bay.

Seward Shipyard Mobile Shipyard

The Seward Shipyard has developed mobile shipyard crews, significantly increasing its capacity for servicing the marine repair and vessel maintenance needs of the Alaskan Fleet.  These mobile shipyard crews enable our facility to provide convenient services for vessels that may be unable to easily travel to our facility.  Additionally, emergency or otherwise urgent needs that do not allow for vessel transport to the shipyard, can be addressed by our mobile shipyard crews.

CONTACT US

3306 Sorrel Road, Seward, Alaska 99664
Phone: 1.907.224.3198
Email: [email protected]

JAG Alaska Inc. is a government approved small business set aside vendor.



JAG ALASKA INC., SEWARD SHIPYARD FACILITY SPECS

DRY DOCKS

SYNCROLIFT

  • LENGTH: 350 ft (107 m)
  • WIDTH: 80 ft (24 m)
  • CAPACITY: 5,000 LT
  • TRANSFER: 3 side rail berths from 180 ft (55 m) to 350 ft (107 m)

TRAVELIFT

  • LENGTH: 130 ft (40 m)
  • WIDTH: 29 ft (9 m)
  • CAPACITY: 330 LT

2 CRANES

  • CAPACITY: Up to 100t

1 PIER

  • TOTAL LENGTH: 300 ft (91 m)

2 SIDE RAIL BERTHS

  • NORTH RAIL: 181 ft (55m)
  • SOUTH RAIL: 500 ft (152m)

Sockeye Point Facility

  • 45 acres for overflow vessels, airbag operation, pier space, hydraulic winch system, short and long term vessel storage, 5,000 sq ft heated shop with overhead crane.

Access to North Dock with all services

  • 400’ pier space

OTHER SPECIFICATIONS

  • 11-acre facility
  • 35,000 sq ft (3,250 m2) of covered work area
  • 18 acres within the Seward Marine & Industrial Center
  • 14 acres shipyard proper with 35,000 sq ft covered work area
  • 2.5 acres with 12,000 sq ft work area
  • 1.5 acres with 1,200 sq ft heated shop
  • Marine rails and transfer carriages for 4 large vessels
  • Full-service shipyard
